Diamond Product Core Cut CC3500L 30" Walk-Behind Saw - 20HP, 460V, 3PH
Diamond Products CC3500 30" Electric Walk-Behind Saw
- Great mid-size saw for service, utility work and rental
- Jack shaft allows full engine power
- Easy to maneuver self propelled drive
- Engine adjustment mechanism for belt tightening and maintenance
- Strongest frame on the market
- 30% more torque with new jack shaft design (on gas models)
- Fits through a 30” door frame
Cc3500L 460V, 3Ph, 30” Blade Guard, 20Hp, Self-Propelled, Electric Start W/ Baldor Engine. Shop With Esch Construction Supply For Top-Quality Tools And Equipment, Backed By Expert Knowledge And Exceptional Customer Support.
| Specification | Details |
|---|---|
| Maximum depth of cut with 14” blade | 4-3/8” |
| Maximum depth of cut with 20” blade | 7-3/8” |
| Maximum depth of cut with 26” blade | 10-3/8” |
| Maximum depth of cut with 30” blade | 2-3/8” |
| Blade shaft diameter | 1-3/4” |
| Arbor size | 1” w/drive pin |
| Blade shaft drive | 6 belt |
| Blade mounting | Right or Left |
| Blade raise & lower | Electro-hydraulic pump |
| Transmission | Eaton Model 10 |
| Drive speed | 0-200 feet/min |
| Air filter | 4 stage |
| Fuel capacity (gas models) | 6 gallons |
