BW Manufacturing SCB-1200-K Chassis
SCB‑1200‑K Ride-On Chassis
One ride-on machine. Endless surface prep possibilities. The SCB‑1200‑K Chassis is designed to adapt fast, letting you switch between shot blasting, scarifying, and diamond grinding—so you can tackle a variety of jobs with just one platform.
Key Benefits & Features
- Interchangeable attachments – Easily swap between blasting, grinding, or scarifying heads without needing a second machine.
- Removable dust bin – Simplifies jobsite cleanup and dumping; less downtime, more productivity.
- Compact ride-on design – Fits through standard doorways but brings serious performance to industrial floors.
- Built-in dust control – Keeps your work area cleaner and compliant with jobsite safety standards.
- Heavy-duty build – Built to run hard every day on concrete, asphalt, and steel surfaces.
Ideal For
- Shot blasting concrete or steel decks
- Grinding coatings or adhesives off large floors
- Scarifying uneven or damaged concrete
- Commercial, industrial, or DOT projects
Why Choose the SCB‑1200‑K?
- One chassis. Multiple tools. Maximize your ROI with a versatile platform built for high-output prep.
- Operator comfort & safety – Ride-on design reduces fatigue while maintaining precision control.
- Modular and maintainable – Swap parts and attachments quickly to stay on schedule.
| Interchangeable Head | Shotblast Scarifier Diamond Grinder Magnet/Broom |
|---|---|
| Tires | Non-marking |
| Length | 81” (206 cm) |
| Width | 35” (89 cm) |
| Height | 54” (137 cm) |
| Weight | 1200 lbs (544 kg) |
| Engine | Kubota D902-E3B Tier IV Diesel 24.8 hp |
| Drive | Hydrostat |
| Compressor | 4.5 CFM |
| Vacuum | 1480 CFM |
| Steering | Manual |
| Collector Capacity | 3.8 cubic ft |
| Aisle Width Min | 54” (137 cm) (Blastable Width) |
